KineMAX 6K Basic

You can configure your KineMAX based on your current Lens, Accessories, monitors and Budget, because KineMAX adapts general display ports, wide range input voltage, and mounting options.

For the color of camera body, you could choose Black or Titanium Grey. Attention, The exterior color of mount  is black or steel anyway.

For the choice of mount, it depends on your lens resources and consideration of future usage.

1. Body with Native Active EF mount: support iris-control for majority of EF lens.  KineRAW displays Iris number and tune it directly. Also you can just disable electronic active EF mounting adapter so that protects it from all-metal lens backend. It is an economical choice if your all lens are EF lens. Check the compatible lens white list
2. Body with KineMOUNT: can be regarded as omni-mount system. If you have EF lens, and PL mount lens, or may rent PL mount lens in future, your best choice is to buy body of KineMOUNT. KineRAW-MINI with PL mount may be most economical PL cinema camera so far.

As long as you choose KineMOUNT camera body, you could get max freedom for lens choice: you may be able to use all kinds of lens for S35mm:

1. If you use Canon EF lens, need to buy Active EF mounting adapter (Active K2EF);
2. If you use Nikon len, need to buy Nikon mounting adapter (K2F);
3. If you use PL cine lens, need to buy PL mounting adapter (K2PL);
4. If you use B4 mount lens, need to buy B4 mounting adapter (K2B4);
5. If you have OCT-19 lens, need to buy OCT-19 mounting adapter (K2OCT19).

Every mounting adapter or mount from Kinefinity is all lock-type mount, like cinema PL mounting lock way. It provides much better stability; fits very well in professional way when video shots using follow-focus gear.

In-camera options, means they are built-in before shipment. You need to return camera body to Kinefinity for later purchase. It may take 3~5 working days for it.

1. KineMAX 6K Option: The option can enable following recording as: 6K, 6K Wide, Golden 3K and Native 4K 4:3 Anamorphic。Record format as KineRAW(.krw). It does not need to return Camera back to factory to upgrade the option so that you can purchase it and upgrade it after you bought camera.
2. KineMAX HiSpeed Option: The option can enable following recording as: 4K wide slow to 100fps, 2K Wide to 144fps. Record format as KineRAW(.krw).
3. KineMAX Battery Plate Option: KineMAX provides integrated battery plate, you can choose SONY V-mount or Anton Bauer Mount. It reduces the connections between camera body and battery, and reduces possibility of power failure. Large Broadcasting Battery located at the back end will help balance when shoulder pack. Besides, camera body output two extra 12V, 1A DC outputs to field monitor or EVF.
4. Dual 3G SDI Monitoring Option: supports SDI monitoring output for broadcasting monitors, the resolution is same as HD display output as 1080p or 720p.
5. 3D SYNC Option: KineMAX can take real 3D shots. Just one SYNC cable to connect two KineMAX SYNC port, set up Master and Slave instantly. 3D SYNC means: Scan sync, frame sync and time code sync, less than 5uS of mismatch!
6. WIFI Control Option: Control camera by wifi control app (KineRemote) on iPad now. Download App directly from Apple App Store.

There are many available accessories for KineMAX camera: not only from Kinefinity, but also from third-party companies, off-the-shelf, qualified and verified by Kinefinity:

1. Phantom 48V audio module with dual XLR inputs: KineAudio;
2. Multi-function control and battery holder: KineGrip;
3. High-speed, reliable and professional KineMAG SSD;
4. Movcam basic KIT, specially for KineMAX: KineKIT;
5. Maybe best third-party EVF: Alphatron EVF;
6. High performance-to-price ratio EVF: Cineroid EVF4C ;
7. Power cord: D-Tap to Power Cord.

There are more accessories as follows:

1. More KineMAX Accessories from Kinefinity，including cables, solid cases, etc.;
2. More Movcam General Accessories, including follow-focus, Matte-box, quick plate, power plate, etc. ;
3. More Third-party high quality accessories，like professional wireless monitoring solution, De-noise software, Resolve Tutorials, etc.

---
